Quick Start Section
Featured Products
Note: The UK warehouse is not includes the USB cable, please note about this before buying.
If you need the cable, you can buy
Specification:
Have changed the USB chip, improve the download speed and stability of WIN7/WIN8
Note: Need to install CH341SER driver, here is the link:
Microcontroller ATmega328
Operating Voltage (logiclevel): 5V
Input Voltage (recommended): 7V ~ 12V
Input Voltage (limits): 6V ~ 20 V
Digital I/O Pins: 14 (of which 6 provide PWM output)
Analog Input Pins: 8
DC Current per I/O Pin: 40mA
Flash Memory: 32KB (ATmega328) (of which 2 KB used by bootloader)
SRAM: 2KB (ATmega328)
EEPROM: 1KB (ATmega328)
Clock Speed: 16MHz
Package included:
1 x Improved Version Nano V3.0
RETURN POLICY:
If your product arrives damaged or is not working, you can return it to us within 3 days after delivery or 30 days after shipment in case the delivery date is not traceable.If the item is still within the validity period of this warranty:We will reimburse you for the return shipping fees after the defective item has arrived in our warehouse. Any further costs incurred during the return process will be at the customer's expense.If the item is outside the validity period of this warranty:The customer shall be held responsible for all the shipping fees and charges when returning the defective product.Return a DOA (dead on arrival) item If the item arrived broken, please contact us within 3 days from the delivery date and follow the procedure for the 3 Days Product Guarantee.If the item has a high value, we may ask you to return it. Please include all of its accessories, like cables, chargers, batteries, in the returned parcel. If an accessory or component is missing, we will ask you to pay for it. All the return shipping fees will be covered by us.
SHIP TO CANADA : USA, CANADA
Average Shipping days: 4
FNIRSI DSO-TC2 Digital Oscilloscope Portable Handheld Lcr Meter 2-in-1 Electronic DIY Testing Teaching Multi-function
Features:
--FNIRSI-TC2 ingeniously integrates digital oscilloscope, electronic component tester, PWM signal generator and other functions into one. Equipped with large-size color dot matrix TFT display. Built-in rechargeable lithium battery. Bring more practical functions to users with a small size, Also has good portability.
--FNIRSI-TC2 has various working modes such as oscilloscope and component tester.Each time you click the power button, it will enter the mode selection interface.Press the [Up] and [Down] keys of the direction keys to select,Select "Mos Test" item, press [OK] key to enter component tester mode;Select the "Oscilloscope" item, press [OK] key to enter the oscilloscope mode.
--"Mos Test" mode can test various types of transistors, and can identify device type, pin polarity, hFE, turn-on voltage, junction capacitance; can test capacitance, resistance, inductance components, etc.
--FNIRSI-TC2 is especially suitable for fast pairing of transistors, identification of mixed surface mount and wordless components, and preliminary screening of small batch components. "Oscilloscope" mode to test the signal waveform of the circuit. Support online operation with computer, you can refresh the official firmware by yourself and complete the upgrade. It is hoped that FNIRSI-TC2 can make the study and work of the majority of users more efficient and interesting.
Name: FNIRSI DSO-TC2 Portable Digital Oscilloscope
Real-time sample rate: 2.5MS/s
Analog bandwidth: 0 ~200kHz
Input resistance: 1MQ
Coupling: AC/DC
Test voltage range: 1:1 probe: 80Vpp (±40V); 10:1 probe: 800Vpp (±400V)
Vertical sensitivity: 10mV/Div ~ 10V/Div (in 1-2-5 increments)
Vertical displacement: Adjustable, with indication
Horizontal time base range: 10μs/Div~ 500s/Div (in 1-2-5 increments)
Trigger mode: Automatic, Regular and Single
Packing list:
Standard Version:
DSO-TC2 Tester x 1
Type-C Cable x 1
Test Book x 3
Regular Probe x 1
Premium Version:
DSO-TC2 Tester x 1
Adapters x 1
P6100 High Voltage Probe x 1
Type-C Cable x 1
Test Book x 3
Regular Probe x 1
Note:
Due to manual measurement, please allow 1-3 cm error, thank you
Due to screen and other objective reasons, there may be a certain color difference, please understand.
IMPORT: THIS ITEM IS SHIPPED FROM CHINA. PLEASE EXPECT UP TO 25 DAYS FOR DELIVERY
RETURN POLICY:
Products can be returned within 30 days. Shipping is not refundable on returns. Returns are accepted only on defective items only.
SHIP TO CANADA : USA, CANADA
Average Shipping days: 4
Features:
1. The only skid drive on the market machined from a single piece of aluminum
2. Covered in silicone it also features a ball bearing mounted on the swivel top for ease of operation.
Name: Computer Repair Kit
Material: Chrome Vanadium Steel
Color: as picture shown
Drill bits include: nut driver 2.5, 3, 3.5, 4, 4.5, 5mm
Hex size 0.7, 0.9, 1.3, 1.5, 2, 2.5, 3, 3.5, 4mm
Five petal size 0.8, 1.2mm
Square size SQ0, SQ1
Torx sizes T3, T4, T5, T6, T7
Torx Safe T8, T9, T10, T15, T20
Three-point 2.3mm
Compatible For Phillips sizes PH000, PH00, PH0, PH1, PH2
Triangle size 2,2.3 mm
Flat size 1,1.3,1.5,2,2.5,3,3.5,4mm
Pozidrive sizes PZ000, PZ00, PZ0, PZ1, PZ2
130MM Magnetic Flexible Extension Rod
Packing list:
1 x Computer Repair Kit
Note:
Different displays may cause the color of the item in the picture a little different from the real thing.
Manual measuring,please allow 1~3mm error,thank you.
RETURN POLICY:
Products can be returned within 30 days. Shipping is not refundable on returns. Returns are accepted only on defective items only.
SHIP TO CANADA : USA, CANADA
Average Shipping days: 4
RETURN POLICY:
Products can be returned within 30 days. Shipping is not refundable on returns. Returns are accepted only on defective items only.
SHIP TO CANADA : USA, CANADA
Average Shipping days: 4
Topic 1: Electricity
Electricity feels mysterious at first because you cannot watch it the way you can watch a bike move or water pour from a bottle. You mostly notice electricity by its results: a lamp turns on, a speaker makes sound, a phone charges, or a game console starts up. That can make electronics seem like magic, but it is not magic. It follows a few simple rules, and once those rules make sense, the rest of beginner electronics becomes much easier to understand.
A strong first picture is to imagine a closed loop of track. If there is a train on the track, it can only keep moving if the track forms a complete path. If a section of track is missing, the train cannot continue. A simple circuit works the same way. Electricity needs a complete path. If the path is broken anywhere, the flow stops
. Another helpful analogy is water in a pipe. Voltage is like pressure. It is the push that tries to move charge. Current is the actual flow. Resistance is anything that makes the flow harder. These are not perfect one-to-one matches, but they are good beginner pictures because they explain why some parts push, some parts carry, and some parts slow things down.
That idea leads to one of the biggest lessons in electronics: components do not just sit next to each other, they each play a role in the path. Wires connect the path, a power source provides push, and a component such as a light or motor uses that moving energy to do something visible. Once students understand that a circuit is a complete loop with jobs assigned along the way, electricity stops feeling random and starts feeling logical.
Topic 2: Basic Components
Topic 3: Micro Controllers
Topic 4: Sensors
Learn and Build
Our Wizards Rules
Our goal is to provide a local source for electronics components, both in our Edmonton area and to Canada.
Our commitment is to provide quality parts and services while working with our community to provide what our customers want.
A bit about me.
As a life long tinkerer and professional tradesman, my life is all about making things that work. Starting as a younger me learning about computers, to re-discovering electronics as an adult, I live to build. My goal is to help people get what they need to see their own interests grow and help their visions come to life. Nothing quite beats the feeling of watching what lived in your head find a place in the real world.
